シミュレーション
システム管理者は、2 つのブランチ オフィス間のサイト間 VPN を構成しています。一部の設定は既に正しく構成されています。構成を完了するために、システム管理者には次の要件が提供されています。
- 最も安全なアルゴリズムを選択する必要があります
- すべてのトラフィックはVPN経由で暗号化される必要があります
- 2つのVPNを認証するために秘密のパスワードが使用されます
コンセントレータ
説明書
2 つの VPN コンセントレータをクリックして、適切な設定を構成します。
いつでもシミュレーションの初期状態に戻したい場合は、「すべてリセット」ボタンをクリックしてください。





正解:
See below explanation
VPN Concentrator 1 (Branch Office 1) Configuration:
Phase 1:
Peer IP address: 5.5.5.20 (IP of VPN Concentrator 2)
Auth method: PSK (Pre-Shared Key)
Negotiation mode: MAIN
Encryption algorithm: AES256
Hash algorithm: SHA256
DH key group: 14
Phase 2:
Mode: Tunnel
Protocol: ESP (Encapsulating Security Payload)
Encryption algorithm: AES256
Hash algorithm: SHA256
Local network/mask: 192.168.1.0/24
Remote network/mask: 192.168.2.0/24
VPN Concentrator 2 (Branch Office 2) Configuration:
Phase 1:
Peer IP address: 5.5.5.10 (IP of VPN Concentrator 1)
Auth method: PSK (Pre-Shared Key)
Negotiation mode: MAIN
Encryption algorithm: AES256
Hash algorithm: SHA256
DH key group: 14
Phase 2:
Mode: Tunnel
Protocol: ESP (Encapsulating Security Payload)
Encryption algorithm: AES256
Hash algorithm: SHA256
Local network/mask: 192.168.2.0/24
Remote network/mask: 192.168.1.0/24
