These are the three steps that the administrator must take to increase throughput to the host. According to the network diagram, the host has two 10Gb interfaces and two 1Gb interfaces in the default bond, but only one of the 10Gb interfaces is connected to a switch. The other 10Gb interface is disconnected and has a red "X" on it. The two 1Gb interfaces are also disconnected and have dotted lines. This means that the host is using only one 10Gb interface for all its network traffic, which limits its maximum bandwidth to 10 Gbps.
To increase the throughput, the administrator should connect both 10Gb interfaces to the physical switch, preferably to different switches for redundancy and high availability. This will allow the host to use both 10Gb interfaces for network traffic, which can increase its maximum bandwidth to 20 Gbps. However, this also requires changing the bond mode from active-backup to balance-slb or balance-tcp, which are load balancing modes that distribute network traffic across multiple interfaces based on source MAC address or TCP session1. The default bond mode of active-backup only uses one interface at a time and switches to another interface only when the active one fails2.
Finally, the administrator should remove any 1Gb interfaces still connected from the default bond, as they are not needed and may cause performance issues or conflicts with the load balancing modes. The 1Gb interfaces can be used for other purposes, such as management or backup networks, by creating separate bonds or bridges for them3. Alternatively, they can be left disconnected if they are not required.
