Explanation

The conditional split transformation routes data rows to different streams based on matching conditions. The conditional split transformation is similar to a CASE decision structure in a programming language. The transformation evaluates expressions, and based on the results, directs the data row to the specified stream.
Box 1: dept=='ecommerce', dept=='retail', dept=='wholesale'
First we put the condition. The order must match the stream labeling we define in Box 3.
Syntax:
<incomingStream>
split(
<conditionalExpression1>
<conditionalExpression2>
disjoint: {true | false}
) ~> <splitTx>@(stream1, stream2, ..., <defaultStream>)
Box 2: discount : false
disjoint is false because the data goes to the first matching condition. All remaining rows matching the third condition go to output stream all.
Box 3: ecommerce, retail, wholesale, all
Label the streams
Reference:
https://docs.microsoft.com/en-us/azure/data-factory/data-flow-conditional-split
